Batch of fabricated boiler coils in the Siddhi Enterprises workshop

07 - Work Gallery

Completed & In-Progress Work

Photographs taken at the MIDC Jejuri workshop - boiler pressure parts, pipe bends, tanks and vessels, fabricated structures, quality checks and dispatch.

Browse the Gallery Discuss a Similar Job

Shop Floor Record

Work carried out at the Jejuri workshop

Filter by work type. Select any photograph to view it enlarged. Images are actual workshop photographs; no client names, project values or completion dates are claimed.

Bed coil assemblies stacked in the fabrication bay — Bed coil assemblies - fabrication bay

Economizer coil batch ready for inspection — Economizer coil batch

Superheater coil elements laid out on the shop floor — Superheater coil elements

Studded bed coils with protective end caps — Studded bed coils

Coil assembly held in a fabrication fixture — Coil assembly in fixture

Assembled coil panel in the alignment frame — Coil panel - alignment frame

Boiler bank tube bends stacked in racks — Boiler bank tube bends

Cold-formed pipe bends stacked after forming — Cold-formed pipe bends

Bundled bends and straight tubes in the yard — Bundled bends - storage yard

Fabricated header pipes ready for despatch — Fabricated header pipes

Welding operation on a bend assembly — Welding - bend assembly

Fabricated vessel shell under assembly — Vessel shell under assembly

Insulated duct and vessel section after finishing — Insulated duct and vessel section

Fabricated hopper section after priming — Fabricated hopper section

Primed structural fabrication awaiting despatch — Structural fabrication - primed

Ultrasonic thickness gauge being used on a formed bend — Thickness check on a formed bend

Fabricated material loaded and lashed for despatch — Loaded and lashed for despatch

Siddhi Enterprises workshop exterior at MIDC Jejuri — Workshop exterior - MIDC Jejuri

About These Photographs

Actual workshop photographs

Every image on this page was taken at the Siddhi Enterprises workshop at Additional MIDC Jejuri, Pune.

Client names, order values and completion dates are not published. For details of a comparable job or to discuss your own scope, contact the technical team.

Need a similar item fabricated? Share drawings, material specification and quantity, and the engineering team will revert with a technical response.
